Acer Nitro 5 AN517-42-R4KN

Operating System
Operating System
Windows 11 Home
Screen
Screen
17.3 inch
CPU
CPU
6800H
RAM
RAM
DDR5-SDRAM
Storage
Storage
1 TB
Resolution
Resolution
1920 x 1080 pixels

Acer Nitro 5 AN517-42-R4KN Prices


Acer Nitro 5 AN517-42-R4KN Key Specifications


Brand
Acer
Model
Acer Nitro 5 AN517-42-R4KN
Version
NH.QGLEV.001
Alias
AN517-42-R4KN
Category
Laptops
Released Date
2022-03-18
Operating System
Windows 11 Home
OS Version
64-bit
CPU
6800H
Graphics Processor
AMD Radeon 680M
RAM
DDR5-SDRAM
RAM Capacity
16 GB
Screen
17.3 inch
Resolution
1920 x 1080 pixels
Storage
1 TB
Weight
3 kg

Acer Nitro 5 AN517-42-R4KN Technical Specifications


Product Overview

Alias
AN517-42-R4KN
Part number
NH.QGLEV.001
Brand
Acer
Family
Nitro
Series
5
Version
NH.QGLEV.001
Model
Acer Nitro 5 AN517-42-R4KN
Category
Laptops
Ean/upc code
4710886810711
Target market
Gaming

Design

BODY

Type
Notebook
Style
Clamshell
Colors
Black
Width (longer side)
400.5 mm
Weight
3 kg
Height (shorter side)
294.5 mm
Thickness (front)
2.7 cm
Thickness (back)
2.79 cm

KEYBOARD

Layout
QWERTZ
Language
German
Backlight color
RGB
Additional features
  • Backlight
  • Full Size Keyboard
  • Numeric Keypad

TOUCHPAD

Pointing device
Touchpad

SECURITY

Lock slot type
Kensington
Additional features
Lock Slot

Camera

FRONT CAMERA

Definition
HD
Resolution (h x w)
1280 x 720 pixels
Additional features
Camera Module

Display

Type
IPS
Definition
Full HD
Diagonal
17.3 inch
Resolution (h x w)
1920 x 1080 pixels
Aspect ratio
16:9
Refresh rate
144 Hz
Surface
Matt
Additional features
LED Backlight

Internal Components

CPU

Number of cores
8
Clock speed
3.2 GHz
Max turbo speed
4.7 GHz
Brand
AMD
Model
6800H
Family
AMD Ryzen 7
Cache
16 MB

RAM

Capacity
16 GB
Maximum capacity
32 GB
Type
DDR5-SDRAM
Slots
1x SO-DIMM
Layout
2 x 8 GB
Form factor
SO-DIMM

GPU

Dedicated card memory
8 GB
Dedicated card memory type
GDDR6
Dedicated card model
NVIDIA GeForce RTX 3070 Ti
Integrated card model
AMD Radeon 680M
Additional features
  • Dedicated Graphics Card
  • Integrated Graphics Card

STORAGE

Total capacity
1 TB

SSD

Capacity
1 TB
Total ssd capacity
1 TB
Number of ssds
1
Storage type
SSD
Ssd interface
PCI Express
Ssd form factor
M.2

BATTERY

Capacity (mah)
90 Wh
Number of cells
4
Type
Lithium-Ion (Li-Ion)

POWER

Power
280 W
Voltage
100 - 240 V
Frequency
50/60 Hz

WIRELESS

Wifi standards
  • 802.11a
  • 802.11b
  • 802.11g
  • Wi-Fi 4 (802.11n)
  • Wi-Fi 5 (802.11ac)
  • Wi-Fi 6 (802.11ax)
Bluetooth version
5.2
Additional features
Bluetooth Module

WIRED

Ethernet speed
  • 10
  • 100
  • 1000 Mbit/s
Additional features
Ethernet Card

AUDIO

Number of speakers
2
Sound system
DTS:X Ultra
Number of microphones
2
Additional features
  • Headphone Microphone Combo Jack
  • Microphone

SECURITY

Password protection
Present
Additional features
Trusted Platform Module (TPM)

SOFTWARE

Operating system version
Windows 11 Home
Operating system bit version
64-bit
Pre-installed software
  • Acer Configuration Manager
  • Acer Portal
  • Norton Internet Security L3 Acer Care Center
Type of password protection
  • BIOS
  • HDD
  • Supervisor
  • User

PORTS

Number of usb 3,2 gen 1 type a ports
1
Number of usb 3,2 gen 2 type c ports
1
Number of usb 3,2 gen 2 type a ports
2
Number of hdmi ports
1
Number of ethernet lan (rj-45) ports
1
