TCL P501M

Operating System
Operating System
Google Android
Screen
Screen
127 mm, 5 inch
Weight
Weight
135 g, 4.76 ounces
Storage
Storage
4 GB
Pixel Density
Pixel Density
196 PPI
Resolution
Resolution
480x854

TCL P501M Prices


TCL P501M Key Specifications


Brand
TCL
Model
TCL P501M
Version
P501M
Category
Smartphones
Released Date
2015-05-01
Operating System
Google Android
OS Version
Google Android 4.4.4 (KitKat)
Graphics Processor
N/A
RAM Capacity
512 MB
Screen
127 mm, 5 inch
Pixel Density
196 PPI
Resolution
480x854
Storage
4 GB
Weight
135 g, 4.76 ounces

TCL P501M Technical Specifications


Product Overview

Brand
TCL
Manufacturer
TCL
Model
TCL P501M
Version
P501M
Category
Smartphones
Country
China

Design

BODY

Height
  • 142.3 mm
  • 5.6 inch
Width
  • 72.3 mm
  • 2.85 inch
Weight
  • 135 g
  • 4.76 ounces
Thickness
  • 0.39 inches
  • 9.8 mm
Colors
White

Camera

BACK CAMERA

Video format
  • 3GP
  • 3G2
  • MPEG4
Image format
JPG
Zoom
1.0 x optical zoom
Sensor
CMOS

Display

Diagonal
  • 127 mm
  • 5 inch
Resolution (h x w)
480x854
Pixel density
196 PPI
Width
  • 62.23 mm
  • 2.45 inch
Height
  • 110.71 mm
  • 4.36 inch
Pixel size
0.12964 mm/pixel
Color depth
24 bit
Subpixels
RGB Matrix (3 subpixels)
Number of colors
16.8M
Screen to body ratio
67.0%
Bezel width
  • 10.07 mm
  • 0.4 inch(es)
Touchpoints
Multi touch
Touch screen type
Capacitive

Internal Components

SOFTWARE

Os
Google Android
Os version
Google Android 4.4.4 (KitKat)

PROCESSOR

Cpu clock speed
1000 MHz
Gpu
N/A

RAM

Capacity
512 MB

STORAGE

Type
Flash EEPROM
Capacity
4 GB
Expansion
  • TransFlash
  • MicroSD
  • MicroSDHC

AUDIO

Channel
stereo
Output
3.5mm
Microphone
mono

CELLULAR

Sim frequencies
  • GSM 900MHz (B8)
  • GSM 1800MHz (B3)
  • GSM 1900MHz (PCS, B2)
  • TD-SCDMA 2000 MHz (B34)
  • TD-SCDMA 1900 MHz (B39)
  • TD-LTE 2600 MHz (Band 38)
  • TD-LTE 1900 MHz (Band 39)
  • TD-LTE 2300 MHz (Band XL) bands
Sim mobile data
  • GPRS (Class unspecified)
  • EDGE (Class unspecified)
  • TD-SCDMA
  • TD-HSDPA
  • LTE (Cat. unspecified) data links
Sim ii frequencies
  • GSM 900MHz (B8)
  • GSM 1800MHz (B3)
  • GSM 1900MHz (PCS, B2)
Sim ii mobile data
  • GPRS (Class unspecified)
  • EDGE (Class unspecified)
Dual sim type
Dual standby
Carrier
China Mobile Limited
Generation
4G
Sim type
Dual

WIRELESS

Bluetooth version
4.0
Bluetooth profiles
  • A2DP
  • AVRCP
Wifi
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Wifi features
Wi-Fi Tethering
Experiences
FM Radio

PORTS

Usb type
  • Type B
  • Micro USB
Usb version
  • 2.0
  • Hi-Speed (480 Mbps)
Usb features
charging

BATTERY

Type
1 cell

LOCATION

Additional features
GPS

SENSORS

Sensors
  • Light intensity sensor
  • Proximity sensor
  • Accelerometer
  • Compass

Not available
