DeviceHD
Smartphones > M3Mobile > M3Mobile M3 Orange > M3-20
M3Mobile M3 Orange

M3Mobile M3 Orange

Operating System
Operating System
Windows Mobile
Screen
Screen
89 mm, 3.5 inch
CPU
CPU
Marvell PXA320 (Monahans P)
Storage
Storage
256 MB
Main Camera
Main Camera
3.1 MP
Resolution
Resolution
240x320

M3Mobile M3 Orange Prices

Amazon

1-3 Day(s)

★★★★☆ 4.7/5
Go to Store
eBay

3-7 Day(s)

★★★★☆ 4.5/5
Go to Store

M3Mobile M3 Orange Key Specifications

Brand
M3Mobile
Model
M3Mobile M3 Orange
Version
M3-20
Category
Smartphones
Released Date
2010-08-01
Operating System
Windows Mobile
OS Version
Microsoft Windows Mobile 6.5 Professional (Titanium)
CPU
Marvell PXA320 (Monahans P)
Graphics Processor
N/A
RAM Capacity
256 MB
Main Camera
3.1 MP
Screen
89 mm, 3.5 inch
Pixel Density
114 PPI
Resolution
240x320
Storage
256 MB
Weight
332 g, 11.71 ounces

M3Mobile M3 Orange Technical Specifications

Product Overview

Brand
M3Mobile
Manufacturer
Mobile Compia
Model
M3Mobile M3 Orange
Version
M3-20
Category
Smartphones
Country
Japan

Design

BODY

Height
  • 166.2 mm
  • 6.54 inch
Width
  • 78.6 mm
  • 3.09 inch
Weight
  • 332 g
  • 11.71 ounces
Thickness
  • 0.98 inches
  • 24.9 mm
Colors
Black/Orange

KEYBOARD

Keys
41

PERIPHERAL

Peripheral
D Pad

Camera

BACK CAMERA

Focus
Contrast Detection Autofocus (CD AF)
Resolution
3.1 MP
Resolution (h x w)
2048x1536 pixel
Image format
JPG
Flash
single LED
Sensor
CMOS

Display

Diagonal
  • 89 mm
  • 3.5 inch
Resolution (h x w)
240x320
Pixel density
114 PPI
Width
  • 53.4 mm
  • 2.1 inch
Height
  • 71.2 mm
  • 2.8 inch
Pixel size
0.2225 mm/pixel
Color depth
18 bit
Subpixels
RGB Matrix (3 subpixels)
Number of colors
262144
Screen to body ratio
29.1%
Bezel width
  • 25.2 mm
  • 0.99 inch(es)
Lcd mode
transflective
Touchpoints
1
Touch screen type
Resistive

Internal Components

SOFTWARE

Os
Windows Mobile
Os version
Microsoft Windows Mobile 6.5 Professional (Titanium)

PROCESSOR

Cpu
Marvell PXA320 (Monahans P)
Cpu clock speed
806 MHz
Gpu
N/A

RAM

Capacity
256 MB

STORAGE

Type
Flash EEPROM
Capacity
256 MB
Expansion
  • TransFlash
  • MicroSD
  • MicroSDHC

AUDIO

Channel
stereo
Microphone
mono

CELLULAR

Sim frequencies
  • GSM 850MHz (B5)
  • GSM 900MHz (B8)
  • GSM 1800MHz (B3)
  • GSM 1900MHz (PCS, B2)
  • UMTS 2100MHz (Band I, IMT)
  • UMTS 1900MHz (Band II, PCS)
  • UMTS 850MHz (Band V, CLR) bands
Sim mobile data
  • CSD 9.6 kbps
  • GPRS (Class unspecified)
  • EDGE (Class unspecified)
  • UMTS 384 kbps (W-CDMA)
  • HSDPA (Cat. unspecified) data links
Generation
3G
Sim type
Single

WIRELESS

Bluetooth version
2.0 + Enhanced Data Rate
Wifi
  • IEEE 802.11a
  • IEEE 802.11b
  • IEEE 802.11g
Experiences
FM Radio

PORTS

Usb type
Proprietary
Usb version
  • 1.1
  • Full-Speed (12 Mbps)
Usb features
  • charging
  • Host
  • Power Delivery
Serial connector
Proprietary
Serial bit rate
115200 bps
Serial standard
Recommended Standard 232

BATTERY

Type
Lithium-ion
Cell i
3300 mAh
Style
Removable

LOCATION

Chip
SiRFstarIII
Additional features
GPS

SENSORS

Sensors
  • Accelerometer
  • 1D barcode scanner

Not available

Sensor
Front Camera
AV Out
AV Out
SIM II Frequencies
Dual SIM
FM Radio
FM Radio
Accelerometer
Accelerometer
