HTC P3600

Operating System
Operating System
Windows Mobile
Screen
Screen
70 mm, 2.8 inch
CPU
CPU
Samsung SC32442
RAM
RAM
SDRAM
Storage
Storage
128 MB
Main Camera
Main Camera
1.9 MP
Battery
Battery
1500 mAh

HTC P3600 Prices


HTC P3600 Key Specifications


Brand
HTC
Model
HTC P3600
Version
Trinity
Alias
HTC Trinity 100
Category
Smartphones
Price
387 USD
Released Date
2006-09-01
Operating System
Windows Mobile
OS Version
Microsoft Windows Mobile 5.0 for Pocket PC Phone Edition (Magneto), AKU 3.0.0
CPU
Samsung SC32442
Graphics Processor
N/A
RAM
SDRAM
RAM Capacity
64 MB
Main Camera
1.9 MP
Screen
70 mm, 2.8 inch
Pixel Density
145 PPI
Resolution
240x320
Storage
128 MB
Battery
1500 mAh
Weight
143 g, 5.04 ounces

HTC P3600 Technical Specifications


Product Overview

Brand
HTC
Manufacturer
HTC
Model
HTC P3600
Version
Trinity
Category
Smartphones
Alias
HTC Trinity 100

Design

BODY

Height
  • 108 mm
  • 4.25 inch
Width
  • 58.2 mm
  • 2.29 inch
Weight
  • 143 g
  • 5.04 ounces
Thickness
  • 0.72 inches
  • 18.4 mm
Colors
  • Silver
  • Black

PERIPHERAL

Peripheral
  • D Pad
  • Pressable rotary scroll wheel

Camera

BACK CAMERA

Resolution
1.9 MP
Resolution (h x w)
1600x1200 pixel
Video format
  • 3GP
  • MPEG4
  • MJPG
Video resolution
320x240 pixel
Image format
  • BMP
  • JPG
Zoom
1.0 x optical zoom
Sensor
CMOS

FRONT CAMERA

Resolution
0.3 MP
Resolution (h x w)
640x480 pixel
Video resolution
640x480 pixel
Video format
  • 3GP
  • MPEG4
  • MJPG
Image format
  • BMP
  • JPG
Sensor
CMOS

Display

Diagonal
  • 70 mm
  • 2.8 inch
Resolution (h x w)
240x320
Pixel density
145 PPI
Width
  • 42 mm
  • 1.65 inch
Height
  • 56 mm
  • 2.2 inch
Pixel size
0.175 mm/pixel
Color depth
16 bit
Subpixels
RGB Matrix (3 subpixels)
Number of colors
65536
Screen to body ratio
37.4%
Bezel width
  • 16.2 mm
  • 0.64 inch(es)
Lcd mode
transflective
Touchpoints
1
Touch screen type
Resistive

Internal Components

SOFTWARE

Os
Windows Mobile
Kernel version
5.1.342
Os version
  • Microsoft Windows Mobile 5.0 for Pocket PC Phone Edition (Magneto)
  • AKU 3.0.0
Additional features
Voice Command

PROCESSOR

Cpu
Samsung SC32442
Cpu clock speed
400 MHz
Gpu
N/A

RAM

Type
SDRAM
Capacity
64 MB

STORAGE

Type
Flash EEPROM
Capacity
128 MB
Expansion
  • SDIO
  • MiniSD
  • MiniSDHC

AUDIO

Chip
Asahi Kasei AK4641
Adc resolution
16 bit
Adc frequency
44100 Hz
Dac frequency
44100 Hz
Dac resolution
16 bit
Channel
stereo
Output
Proprietary
Microphone
mono

CELLULAR

Sim slot
Mini-SIM (2FF)
Sim frequencies
  • GSM 850MHz (B5)
  • GSM 900MHz (B8)
  • GSM 1800MHz (B3)
  • GSM 1900MHz (PCS, B2)
  • UMTS 2100MHz (Band I, IMT)
  • UMTS 1900MHz (Band II, PCS)
  • UMTS 850MHz (Band V, CLR) bands
Sim mobile data
  • CSD 9.6 kbps
  • GPRS (Class unspecified)
  • GPRS Class 10
  • EDGE (Class unspecified)
  • UMTS 384 kbps (W-CDMA)
  • HSDPA (Cat. unspecified) data links
Generation
3G
Sim type
Single

WIRELESS

Bluetooth version
2.0
Wifi
  • IEEE 802.11b
  • IEEE 802.11g
Experiences
  • FM Radio
  • Infrared

PORTS

Usb type
  • Type B
  • Mini USB
Usb version
  • 1.1
  • Full-Speed (12 Mbps)

BATTERY

Type
Lithium-ion — 1 cell
Cell i
1500 mAh
Capacity
1500 mAh
Style
Removable
Current
125 mA
Life
12.0 hours

LOCATION

Chip
Qualcomm MSM6275 gpsOne
Additional features
GPS

SENSORS

Sensors
Accelerometer

SAR

Head (usa)
0.977 W/kg

Not available
